Fluke iSee Mobile Thermal Camera TC01A/TC01B

256 x 192 pixels, detailed image quality
Up to 550 °C, suitable to use in many applications
±2% or ±2 °C accuracy, reliable and stable
25 Hz frame rate for smooth video recording

Category: Thermal Cameras

Description
Additional information
Specifications
Models

Description

The Fluke iSee Mobile Thermal Camera is a compact and powerful tool designed to help you identify potential problems in electrical systems, HVAC systems, and building structures. This innovative device offers a wide range of features and benefits:

Key Features:

High-Quality Thermal Imaging: Captures detailed thermal images with a 256 x 192 pixel resolution, allowing you to visualize temperature differences and identify potential issues.
Wide Temperature Range: Measures temperatures from -10°C to 550°C, making it suitable for a variety of applications.
High Thermal Sensitivity: Detects even subtle temperature variations with a thermal sensitivity of 50 mK (0.05°C).
Real-Time Analysis: Quickly identify hot spots and cold spots with real-time temperature measurements and analysis tools.
Easy-to-Use App: The intuitive app allows you to capture, analyze, and share thermal images and videos.
Compact and Lightweight Design: Easily portable and convenient to use.
Durable Construction: Built to withstand harsh environments.

Benefits:

Preventative Maintenance: Identify potential problems before they escalate into costly failures.
Improved Efficiency: Optimize energy usage by identifying inefficient areas.
Enhanced Safety: Detect electrical hazards and other safety risks.
Faster Troubleshooting: Quickly pinpoint the root cause of problems.
Professional-Grade Performance: Offers features and performance comparable to larger, more expensive thermal cameras.

The Fluke iSee is a valuable tool for anyone who needs to perform thermal inspections, including electricians, HVAC technicians, building inspectors, and homeowners. With its compact size, powerful features, and easy-to-use app, the iSee makes thermal imaging accessible to everyone.

Additional information

Brand	Fluke

Specifications: Fluke iSee™ Mobile Thermal Camera – TC01A/TC01B

	TC01A	TC01B
Performance Specifications
IR resolution	256 x 192
Pixel size	12 μm
Temperature range	-10 °C to 550 °C/14 °F to 1022 °F	-20 °C to 550 °C/-4 °F to 1022 °F
Temperature accuracy	± 2 % of rdg or ± 2 °C/3.6 °F, whichever is greater (@ 23 °C ± 5°C/73.4 °F ± 9 °F ambient temperature)
Temperature measurement distance	0.25 m to 5 m (* -20 ℃/-4 °F to 10 ℃/50 °F, only for 0.25 m to 3 m)
Frame rate	25 Hz
Warm-up time	1 minute
Focal length	Fixed focal length: 3.2 mm
Shutter mode	Internal
Thermal sensitivity (NETD)	50 mK
Spectral range	8 to 14 μm
Field of view (H x V)	56° x 42°
Spatial resolution	3.81 mrad
General Specifications
USB interface	Type-C	Lightning
Operating temperature	0 ℃ to 40 ℃/32 °F to 104 °F
Storage temperature	-30 ℃ to 60 ℃/–22 °F to 140 °F
Operating humidity	10 % to 90 % RH, non-condensing
Power consumption	350 mW (Typical)	200 mW (Typical)
Drop test	1 m/3.3 ft
Ingress protection	IEC 60529: IP54 (with the protective cover for Type C)	IEC 60529: IP56
Operating altitude	2 000 m/6 562 ft
Storage altitude	12 000 m/39 370 ft
Dimensions (L x W x H)	60 x 33.5 x 11.2 mm/2.36 x 1.32 x 0.44 in
EMC Environment	International IEC 61326-1: Electromagnetic environment for portable equipments CISPR 11: Group 1, Class A Group 1: Equipment has intentionally generated and/or uses conductively-coupled radio frequency energy that is necessary for the internal function of the equipment itself. Class A: Equipment is suitable for use in all establishments other than domestic and those directly connected to a low-voltage power supply net- work that supplies buildings used for domestic purposes. There may be potential difficulties in ensuring electromagnetic compatibility in other environments due to conducted and radiated disturbances. Caution: This equipment is not intended for use in residential environments and may not provide adequate protection to radio reception in such environments. Korea (KCC) Class A Equipment (Industrial Broadcasting and Communication Equipment) Class A: Equipment meets requirements for industrial electromagnetic wave equipment and the seller or user should take notice of it. This equipment is intended for use in business environments and not to be used in homes. United States (FCC) 47 CFR 15 Subpart B. This product is considered an exempt device per clause 15.103.
